Installation Tools

Reel Trailers

Cable reel transport and deployment trailers for fiber optic cable, strand, innerduct, and conduit. Galloway stocks reel trailers from Rally Trailer Manufacturing (Mona, Utah) and Roose in manual, self-loading, and hydraulic configurations. All Rally trailers feature 2.5” steel roller bars with locking collars, LED lights, electric brakes, pintle hitch, and meet DOT safety ratings.

Speak to a specialist call
Galloway_Tools_Reel_Trailer_S

Rally Trailer specifications (Manufacturer data)

Model GVWR Payload Reel Dia Width Len Bar Cap Positions
Single Manual 6,000/7,500 5,000/6,500 96" 63" 11' 6,500 lbs 1
2-Place Manual 14,000 10,000 102" 63" 23' 4,000 lbs/bar 2
3-Place Manual 16,000 12,000 102" 63" 32' 8,000 lbs/bar 3
3-Place Micro Duct — — — — — — 3
SLRT-17 Self-Loading 9,500 7,000 120" 65" — 7,000 lbs lift 1
RFDT Rapid Fiber 10,000 8,500 120" 63" — 8,000 lbs lift 6 arbors
6-Pos Elec Hydraulic 9,140 8,000 120" 60" 13' 8,000 lbs lift 6
DF6 Compressor Trailer 12,000 8,000 60" 48" 15' — 1 + blower

Source: rallytrailermfg.com individual model pages (2025–2026). GVWR and payload in lbs. “—” = spec not confirmed on manufacturer website. 3-Place Micro Duct and 10-Reel Cable Conduit models referenced in prior drafts but no spec pages found on Rally’s site—may be custom/special order.

Standard Features (All Rally Trailers)

  • bookmark_check
    2.5” / 2 5/8” steel roller bars with locking collars and centering cones
  • bookmark_check
    LED lights, electric brakes, pintle hitch
  • bookmark_check
    Document holder, tire chocks with aluminum holders
  • bookmark_check
    DOT safety rated; 215/75R 17.5 tires (manual models)

Self-Loading & Hydraulic Features

  • bookmark_check
    SLRT-17: 14 HP onboard engine, hydraulic lift to 7,000 lbs. One-operator loading without forklift or crane
  • bookmark_check
    RFDT: 23 HP Honda electric-start, 6 hydraulic arbors, adjustable hydraulic payoff wheel, pinless locking, equipment mounting carriage. Options: remote control, custom colors
  • bookmark_check
    6-Pos Electric Hydraulic: Electric over hydraulic pump (power up/power down), 8,000 lbs lift, pinless locking, galvanized finish available
  • bookmark_check
    DF6: Integrated Plumettaz DF6 Cable Pusher + 185 CFM Sullair compressor, 22 HP motor, hydraulic turret with 360° rotation, gear-driven rewinder

Brands we carry

Need Reel Trailers for Your Crew?

Galloway stocks Rally Trailer and Roose reel trailers across our distribution network. Whether you need a manual trailer for residential fiber builds or a hydraulic self-loading unit for heavy reel handling, our team can help ensure the right configuration is specified and delivered.
