Conduit & Fittings

Split Steel Couplings & Fittings

Ironhed FMP couplings and fittings complete the split steel conduit system with direction changes, size transitions, conduit connections, and sealed assemblies—all manufactured in the same split two-piece design as the straight sections. Every FMP fitting installs around live utilities without service interruption. Galloway stocks FMP bends, rotator couplers, and gasketing kits from Ironhed.

Speak to a specialist call
Galloway_Pipe_Steel_Coulings_Fittings
Reels in the Yard Greenfield OH SML

Features

The options below are how you spec a fitting — standard angles and the part-numbering that identifies an exact bend, with custom radii, larger sizes, and gasketed versions for anything the standard range doesn't cover.

  • check_circle
    check_circle

    All fittings maintain the split two-piece FMP design

    Install around occupied conduit without pulling cables

  • check_circle
    check_circle

    FMP Bends available in standard angles

    15°, 22.5°, 30°, 45°, 60°, and 90° in all standard sizes

  • check_circle
    check_circle

    Custom radius bends

    Engineered for specific project routing requirements

  • check_circle
    check_circle

    Rotator Couplers (12" and 15" lengths)

    Re-round and join oval or misshapen HDPE innerduct—especially effective in handholes and tight spaces

  • check_circle
    check_circle

    Gasketing kits available for all FMP sizes

    Seal along all flanges and butt seams for waterproofing or secondary containment

  • check_circle
    check_circle

    Larger sizes up to 60" available

    Gasketed versions available for sealed systems

  • check_circle
    check_circle

    Systematic part numbering:

    S(Size) x (Degree) x (Radius) / (Gauge)—e.g., S4x90x36/10 for a 4", 90°, 36" radius bend in 10-gauge

  • ink_highlighter
    ink_highlighter

    Custom engineering available:

    Oversized casing to 144", four-piece assemblies for 42"+ diameters, lifting eyes, powder coating

Hardware Reference

All FMP sections, bends, and couplers ship with appropriate hardware included:

Wall Thickness

Hardware Size

Type

Max Torque

0.074"–0.137"

5/16" x 1" to 1.25"

Gr. 5 zinc flange bolt & nut

13 ft-lbs

0.237"–0.312"

3/8" x 2.5"

Gr. 5 zinc flange bolt & nut

23 ft-lbs

0.375"–0.500"

1/2" x 2.5"

Gr. 5 zinc flange bolt & nut

57 ft-lbs

Upgraded hardware available on request: hot-dip galvanized, stainless steel, and Grade 8 yellow zinc.

Rotator Coupler Specifications

  • Standard wall: 10-gauge galvanized
  • Each coupling includes stainless steel fasteners
  • Available in all standard FMP conduit sizes
  • 12-inch and 15-inch coupling lengths

Gasketing System

All FMP sizes—including rotator couplers—are available with a separate gasketing kit that seals along all flanges and butt seams. The gasketing system provides fluid barrier protection against water, soil, and debris, and converts FMP into sealed secondary containment for industrial applications involving fuel, chemical, or pressurized lines—eliminating the expense and liability of welding near live utilities.



Brands we carry

Need FMP Fittings for your next build?

We stock the complete FMP system—straight sections, bends, couplers, and gasketing kits. For complex projects involving custom radii, oversized casing, or specific loading calculations, we coordinate directly with Ironhed to your project timeline. Tell us your conduit sizes, bend angles, and application—we'll match you with the right fittings.

Not sure exactly what you need? Call and let’s talk about what you’re building — we’ll help work it out.
