Locating & Detection Equipment

Rycom Snaptrack HPTX Specifications

• bookmark_check
  Pathfinder SAF Technology™ with FrequencyFlex™ customizable frequency adaptation
• bookmark_check
  10-watt transmitter with automatic impedance matching (5–25,000 ohms); direct connection, transmitter induction, and coupler induction
• bookmark_check
  Quadruple antennae array: push-button depth, line direction, line orientation, and current measurement
• bookmark_check
  Instant depth measurement up to 25 feet– Active frequencies: 131 kHz, 82.3 kHz, 65.5 kHz, 32.8 kHz, 8.2 kHz, 4.0 kHz, 815 Hz, 512 Hz (and others where permitted)
• bookmark_check
  Passive modes: 50 Hz env, 60 Hz env with LiveSound™, Radio Frequency, CP 50 Hz, Rectified CP 60 Hz
• bookmark_check
  Sonde frequencies: 512 Hz, 640 Hz, 815 Hz, 8 kHz, 33 kHz — traceable 25 ft in air, 10 ft in cast iron
• bookmark_check
  Backlit segmented LCD: bar graph, signal strength, depth, line guidance, battery condition
• bookmark_check
  Li-Ion rechargeable batteries (transmitter and receiver) with AC and DC chargers
• bookmark_check
  Kit includes: receiver, transmitter, protective carrying case, ground rod, direct connection leads (15 ft reach), manual
